4 CH 1080P Mobile DVR for Buses
4 CH 1080P Mobile DVR for Bus
Chinese manufacturer YUWEI is dedicated to the R&D and production of vehicle DVRs. We recommend our hot-selling 2023 model, the F4, a 4 CH 1080P Mobile DVR for Buses. It supports GPS/BDS real-time positioning, 1080p video recording, and 4G/wifi network connectivity. Currently, it is used by over 120 fleets in countries such as Saudi Arabia, Turkey, Mexico, Brazil, France, and the UK.
Whether your company has a few buses or hundreds, our equipment can run smoothly, providing fleet managers with GPS positioning, real-time video monitoring, and remote information processing. This helps to better track and manage your fleet.
The F4 4 CH 1080P Mobile DVR provides comprehensive driving records and video monitoring for buses. With powerful AI computing capabilities, it supports advanced monitoring functions like ADAS, BSD, and DSM, ensuring high levels of intelligent monitoring and overall safety. It is equipped with a leading international visual recognition algorithm engine, providing precise and reliable warnings for dangerous driving and driver status monitoring. It supports remote network upgrades, six channels of analog video input (including 2 channels of 1080P HD video, 2 channels of audio input, 1 channel IPC input, and 1 channel CVBS output), achieving all-around audio and video monitoring and recording. Data can be stored on both hard drives and SD cards, ensuring data security.
Item Specification
Appearance and Structure
- Size: 145×58×193mm
- Shell Material: PC+ABS
- Body Material: Aluminum alloy
Protection Grade
- IP Rating: IP54
Environmental Suitability
- Operating Temperature: -30℃～70℃
- Storage Temperature: -40℃～85℃
Working Voltage
- Range: 9 - 32V
- Protection:
- 8.5V±0.5V/12V system
- 17V±0.5V/24V system
- 12V/24V adaptive (36V not supported)
Power Consumption
- Ultra-low Power Design:
- Static current <2mA
- Zero-power-consumption sleep mode
- Average: <30W
Super Capacitor
- Components: 3 super capacitors
- Function: Save video for 2~3 seconds before power failure
Indicator Lights
- Lights: 4 (positioning, communication, video recording, operation)
External Interface
- Power Supply: TE-1318384-2
- Positioning Antenna: Fakra-C blue
- Communication Antenna: Fakra-D
- Video Interface: M12-4
- IPC Interface: M12-6
Video
- Input: 6 channels AHD/CVBS, 12V, 0.5A per channel
- IPC Input: 1 channel, 12V
- Output: 1 channel CVBS
Audio
- Recording: 2-way, supports key input detection
- MIC Input: 1 way
Storage
- Hard Disk: 2.5-inch, 7mm/9.5mm, max 2TB
- SD Cards: 2 slots, max 512GB each, not simultaneous
Data Interface
- RS232: 2-way, 5V @ 500mA
- 485: 1 way
- IPC: 1 way, 12V (1A)
Modules
- Positioning: GPS and BeiDou
- Communication: 4G
SIM Card
- Type: Drawer plug-in
IO Function
- Inputs: 8 (ACC, left/right steering, door, emergency, reverse, brake, speed pulse)
- Output: 1 (fuel break power)
4 CH 1080P Mobile DVR for Buses cost?
YUWEI standard version Mobile DVR costs $160. We support product customization. Our headquarters is located in Shenzhen, with a 15,000 square meter factory in Dongguan, Guangdong, China, ready to meet all your needs.
